Automatic Transmission Filter Replacement for 31728-1XF02 JF011E | Transmission Oil Filter 20-Bolt Compatible with 2007-2017 Altima Rogue Sentra Juke Lancer Outlander Compass Patriot Caliber
Product details
| Management number | 233931623 | Release Date | 2026/06/27 | List Price | $7.60 | Model Number | 233931623 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Same Spec, Smarter Spend – This Ortopia automatic transmission filter is built to the same hydraulic and filtration specification as OE 31728-1XF02 / 2824A006. Designed for the RE0F10A / JF011E CVT transmission, the filter media captures belt debris and metallic particles before they reach the valve body. Features short inlet design for standard-depth oil pans. Kit includes a pre-formed rubber pan gasket. No downgraded materials, no shortcuts on filtration area. The difference? You pay for the engineering, not the dealership markup.
- Problem & Solution – Fixes CVT shudder at low speed, delayed engagement into Drive, belt slip under acceleration, and P0741/P0776 torque converter/pressure control codes—all traced to restricted fluid pickup from a clogged filter. The JF011E CVT depends on precise line pressure to control the belt and pulley system; a saturated filter starves the pump, causing pressure drops that trigger ratio errors and degraded driveability. This filter restores proper fluid flow and line pressure, eliminating the shudder and hesitation often misdiagnosed as a failing torque converter or worn belt. Performance returns to factory spec without expensive CVT recalibration.
- RPO-Coded Fitment – Direct-fit for RE0F10A / JF011E / CVT2 CVT transmissions with 20-bolt oil pan. Compatible with 2008-2015 Rogue, 2007-2012 Altima, 2007-2012 Sentra, 2008-2017 Outlander, 2008-2017 Lancer, 2011-2017 Outlander Sport, 2007-2017 Compass, 2007-2017 Patriot, 2007-2012 Caliber, 2010-2013 Kizashi. Includes dual gaskets (rubber + composite with metal core). Critical: 20-bolt pan with short inlet—confirm bolt count and inlet type. For full VIN/engine breakdown, see product description. Pro tip: replace external cartridge filter 2824A006 at same service interval.
- Buyer's Checklist – Before clicking buy, confirm THREE things: ① Your transmission is a JF011E / RE0F10A CVT (check fluid spec: Nissan NS-2 or equivalent); ② Your oil pan has 20 bolts; ③ This filter has a SHORT inlet for standard-depth pans. Check VIN 8th digit: W = 2.5L (Rogue, Altima — fits), A = 2.5L (Altima — fits), U = 2.0L (Sentra — fits), C = 2.5L (Sentra — fits), W = 2.4L (Outlander, Lancer — fits), U = 2.0L (Lancer, Outlander Sport — fits), A = 2.0L (Compass, Patriot, Caliber — fits), B = 2.4L (Compass, Patriot — fits). Warning: this is a short-inlet filter for 20-bolt pans. Do not install in long-inlet or different bolt count applications.
- Installation Workflow – ① Lift vehicle, drain fluid, remove 20 pan bolts criss-cross. ② Drop pan, drain residual, clean magnets. ③ Remove old filter: unbolt, pull down. Confirm short inlet match. ④ Gasket: rubber for Nissan/Suzuki, composite/metal for others or corroded flanges. ⑤ Install filter: torque bolts 7-8 ft-lbs (10-11 Nm), ensure inlet fully seats. ⑥ Clean rail, install gasket, torque 20 bolts criss-cross 7-8 ft-lbs. ⑦ Refill NS-2 CVT fluid, check level. Replace external filter 2824A006.
| ASIN | B0BJTVNDBD |
|---|---|
| Brand | Ortopia |
| Model | Transmission Filters |
| Exterior | Chrome |
| Item Weight | 7.8 ounces |
| Manufacturer | Ortopia |
| OEM Part Number | 31728-1XF02 317281XF02 31728-1XF03 31728-1XF0A 2824A006 2824A007 5191890AA 92724H 31397-1XF0C B-235 FK348 TF1218 511637 |
| Item model number | 31728-1XF02 |
| Product Dimensions | 7.56 x 7.17 x 3.11 inches |
| Manufacturer Part Number | 31728-1XF03 31728-1XF02 |
